Graphite Furnace: Yes
Lamps: 8 hollow cathode lamp turrets with 2 lamps simultaneously lit ( one lamp pre-heated )
Maximum Temperature: 2650 °C
Wavelength Range : 190 to 900
Power Requirements: 110V/60Hz or 220V/50Hz three-phase AC
Peak Power: 5000 W (graphite furnace)
Additional Specifications Dimensions
mainframe: 110 cm x 50cm x 45cm
graphite furnace: 50cm x 50cm x 45cm
Monochromator: Czerny-Turner configuration
Spectral Bandwidth: 0.1nm, 0.2nm, 0.4nm, 1.0nm, 2.0nm (5 steps. with automatic changeover)
Wavelength Accuracy: 0.25nm
Wavelength Repeatability: 0.15nm
Baseline Stability: 0.005A/30 min
Sensitivity (Cu): 0.03 Μg/ml/1%
Burner Head: Titanium alloy burner
Nebulizer: High-efficiency glass nebulizer
Atomization Chamber: Corrosion-resistant material
Position Adjustment: Automatic changeover of flame and furnace
Automatic setting of optimum height for flame burner
Safety: Automatic ignition and of mixing air-acetylene gas with safety control
